Video telemetry terminal

【Product introduction】Video telemetry terminal integrates RTU function and video recorder function, widely used in intelligent water conservancy, intelligent water, intelligent industry and other industries.

Model：FT-ZD2

Brand：fengtu

Get a Free Quote

Product details

1. Video telemetry terminal product overview

Video telemetry terminal integrates RTU function and video recorder function, widely used in intelligent water conservancy, intelligent water, intelligent industry and other industries.Video telemetry terminal is an industrial-grade telemetry monitoring device that integrates traditional telemetry terminal functions, 4G wireless, Ethernet transmission, and wireless video monitoring functions to realize hydrology/water resources/environmental protection/energy consumption and other data collection, storage, control, alarm, Transmission, image capture, video overlay and other functions.It supports device communication, has its own IO input and output, and analog quantity collection.It can be used according to the on-site situation.It has video image overlay transmission, data collection and transmission functions, and has logical operation and logic control functions.It is mainly targeted at remote sensing and remote monitoring applications in water resources, water conservancy, hydrology, water environment, environmental protection, industrial meteorology, agriculture, transportation, oil fields and other industries.

2.Video telemetry terminal equipment list

FT-ZD2Video telemetry terminal1 unit

2 3-meter suction cup antennas (4G)

2 rod antennas (WIFI)

1 network cable (1 meter)

1 power supply (AC 220v to DC 12vDC adapter)

1 small screwdriver

1 copy of instruction manual

After unpacking, please count the number of items.The specific quantity is consistent with the user's order contract.If any damage, loss, or accessories are found to be inconsistent, please contact the manufacturer in time.

3.Video telemetry terminal technical parameters

AI input configuration: 2 analog acquisition inputs

DI input configuration: 2 switching inputs

DO output configuration: 1 relay output (optional)

Storage capacity: 64G cycle storage

Equipped with 1 100M WAN port to provide high-speed network connection

Equipped with 4 100M LAN ports, providing high-speed transmission capabilities

Configure hotspot access to the wifi network (initial password 12345678)

Provide high-speed, low-latency, and highly stable 4G network communications

Serial port configuration: 2-way RS485

Power supply: 9V~24V DC.

Average current: <200mA/12V
