electric field monitor

electric field monitor

【Product introduction】electric field monitor can realize remote sensing detection and early warning of lightning and prevent the loss caused by lightning.

Model：FT-DC1

Brand：fengtu

mail

Get a Free Quote

Product details

electric field monitor can realize remote sensing detection and early warning of lightning and prevent the loss caused by lightning.

Device name	electric field monitor
Electric field measurement range	-30kV/m~30kV/m
resolution	20V/m
Accuracy	better than 5%
Detection distance (radius)	15KM
Sensor weight	3 kg
input voltage	24VDC/220VAC
Power consumption	0.65W
size	300mm
working temperature	-40℃~55℃
interface	485
Communication protocol	MODBUS
